Trimble R750 GNSS Receiver

Description

Trimble R750 GNSS Receiver

The Trimble R750 is a high-performance GNSS receiver designed for precision positioning applications. It features an integrated 4G/LTE cellular modem, allowing for robust and flexible connectivity options. The receiver is ideal for base station and rover configurations, providing reliable performance in a variety of environments.

Key Features:

Configuration Options

• The R750 offers a range of upgradeable configurations, including:
  • Precise Rover
  • Precise Base
  • BeiDou tracking (B1, B1C, B2, B2A, B2B, B3)
  • Galileo tracking (E1, E5-A, E5-B, E5-AltBOC, E6)
  • Premium Precise Rover (Precise Rover + BeiDou + Galileo)
  • Premium Precise Base (Precise Base + BeiDou + Galileo)
  • Premium Precise Base and Rover (Precise Base + Precise Rover + BeiDou + Galileo)

This flexibility allows users to tailor the receiver to their specific needs and scale up as required.

Robust GNSS Positioning

• The Trimble R750 delivers precise and reliable GNSS positioning using multiple satellite constellations, including GPS, GLONASS, Galileo, and BeiDou.
• Its rugged design ensures accurate data capture even in challenging conditions.

Advanced Connectivity

• Integrated 4G LTE modem for real-time data transmission and remote connectivity.
• Wi-Fi and Bluetooth support for easy data transfer and connectivity with field devices.
• Ethernet and multiple serial ports (COM1, COM2, COM3/CAN, 1PPS) for flexible communication options.

Extended Battery Life

• Internal rechargeable battery provides up to 4 hours of continuous operation when transmitting at 2W.
• When paired with a 30,000 mAh USB-PD power pack, the receiver can run for approximately 13.9 hours.

Comparison with Other Trimble Models:

Channels

• The R750 supports multiple satellite tracking options with upgradeable configurations.
• It can track GPS, GLONASS, BeiDou, Galileo, and QZSS satellites, ensuring enhanced performance in GNSS-restricted environments.

Precision & Performance

• The Trimble R750 delivers reliable RTK (Real-Time Kinematic) corrections, improving positioning accuracy.
• Supports 1PPS (Pulse Per Second) output, making it suitable for high-precision timing applications.

Functionality

• The R750 features a built-in web interface, allowing for easy configuration and monitoring via a smartphone or computer.
• UHF Radio Antenna compatibility for long-range communications in base-rover setups.
• Ethernet support enables seamless network integration.

Model Variants

• R750-BRO-LT: Base Rover version without IMU enabled (Upgradeable via software).
• R750-BRO: Base Rover version with IMU enabled. Both models include all radios and cellular.

Summary

The Trimble R750 GNSS receiver is a powerful and versatile solution for precision GNSS applications. With upgradeable configurations, advanced connectivity options, and long battery life, it offers superior performance for both base and rover operations.

For more details, visit Trimble R750 Help Guide.
